电动皮卡 Configuration of Electric Pickup-second-generation
Remark:"●"Available "—"Not Available EV Luxury 5seats
（Left hand drive）EV Luxury 2seats
（Left hand drive）EV Luxury 5seats（Right hand drive） EV Luxury 2seats（Right hand drive） 电动两驱短轴五座豪华版
（左舵）电动两驱短轴二座豪华版
（左舵）电动两驱短轴五座豪华版
（右舵）电动两驱短轴二座豪华版
（右舵）
MODEL DYQ1032BEV1-H DYQ1033BEV1-H DYQ1032BEV1R-H DYQ1033BEV1R-H 基本参数 Basic Parameter
变速箱 Transmission / / / / 整车长*宽*高(mm) Vehicle Overall Dimensions (mm) 5330*1870*1864 5330*1870*1864 5330*1870*1864 5330*1870*1864 货箱长*宽*高(mm) Packing box Overall Dimensions (mm) 1575*1610*530 2380*1499*519 1575*1610*530 2380*1499*519 最高车速(km/h) Maximum Speed 120 120 120 120 续航里程（NEDC） Endurance mileage (NEDC) 275 275 275 275 实测离地间隙(mm) Ground Clearance(mm) 210 210 210 210 车身 Car body
轴距(mm) Wheel Base(mm) 3100 3100 3100 3100 前轮距(mm) Front Wheel Base (mm) 1580 1580 1580 1580 后轮距(mm) Rear Wheel Base (mm) 1580 1580 1580 1580 整备质量(kg) Curb Mass (kg) 2000 1900 2000 1900 车身结构 Vechicle Type PICKUP PICKUP PICKUP PICKUP 车门数(个) Door 4 2 4 2 座位数(个) Seat 5 2 5 2 电池容量（kWh） Battery capacity (kWh) 60/65kWh 60/65kWh 60/65kWh 60/65kWh 电池品牌 Battery brand CATL CATL CATL CATL 电池种类 Battery type Lithium iron phosphate Lithium iron phosphate Lithium iron phosphate Lithium iron phosphate 充电标准 Charging standard Chinese standard, Japanese standard, European standard Chinese standard, Japanese standard, European standard Chinese standard, Japanese standard, European standard Chinese standard, Japanese standard, European standard 快充充满电时间（h） Fast charging and full charge time (h) 0.75（20%-80%） 0.75（20%-80%） 0.75（20%-80%） 0.75（20%-80%） 电机 Motor
额定/峰值功率 Rated/peak power(KW) 65/130 65/130 65/130 65/130 额定转速 Rated speed（RPM） 4000 4000 4000 4000 最高转速 Maximum speed 12000 12000 12000 12000 额定转矩 Rated torque 120 120 120 120 最大扭矩(N·m) Maximum torque (N · m) 330N.m 330N.m 330N.m 330N.m 变速箱 TRANSMISSION
挡位个数 Speed / / / / 变速箱类型 Type / / / / 底盘转向 Chassis
驱动方式 Driving Method 2WD 2WD 2WD 2WD 前悬架类型 Front Suspension Double Wishbone Independent Suspension Double Wishbone Independent Suspension Double Wishbone Independent Suspension Double Wishbone Independent Suspension 后悬架类型 Rear Suspension Leaf spring suspension Leaf spring suspension Leaf spring suspension Leaf spring suspension 助力类型 Steering Hydraulic Power Steering Hydraulic Power Steering Hydraulic Power Steering Hydraulic Power Steering 车体结构 Body Structure PICKUP PICKUP PICKUP PICKUP 车轮制动 Wheel Brake
前制动器类型 Front Brake Type Ventilated Disc Ventilated Disc Ventilated Disc Ventilated Disc 后制动器类型 Rear Brake Type Drum Drum Drum Drum 驻车制动类型 Parking Brake Type Hand Hand Hand Hand 前轮胎规格 Front Tyre Size 245/70R17 245/70R17 245/70R17 245/70R17 后轮胎规格 Rear Tyre Size 245/70R17 245/70R17 245/70R17 245/70R17 备胎规格 Spare Tyre no Spare Tyre no Spare Tyre no Spare Tyre no Spare Tyre 轮胎花纹 Tread pattern Road tire Road tire Road tire Road tire 安全装备 Active/Passive Safety
主/副驾驶座安全气囊 Dual Airbags ● ● ● ● 安全带未系提示 Seatbelt Unfastening Warning System ● ● ● ● 车内中控锁 Central Locking ● ● ● ● 遥控钥匙 Remote Key ● ● ● ● 上坡辅助 Uphill assistance ● ● ● ● 碰撞后车门自动解锁 Automatic door unlocking after collision ● ● ● ● 行车自动落锁 Automatic locking of driving ● ● ● ● 操控配置 Control Equipment
ABS防抱死 ABS ● ● ● ● 制动力分配(EBD/CBC等) EBD ● ● ● ● ESC电子防滑系统 ESC / / / / 定速巡航 Fixed-speed cruise / / / / 外部配置 External Equipment
铝合金轮圈 Alum-Alloy Wheel ● ● ● ● 差速锁 differential lock / / / / 上车踏板 Boarding pedal ● ● ● ● 货箱防刮涂层 Anti scratch coating for container ● ● ● ● 防滚架 The roll cage ● ● ● ● 大后保险杠 Large rear bumper ● ● ● ● 小后保险杠 Small rear bumper 选装 选装 选装 选装 内部配置 Internal Equipment
方向盘 Steering Wheel Leather Leather Leather Leather 方向盘调节 Steering Wheel Adjusting Type Up and Down Up and Down Up and Down Up and Down 多功能方向盘 Steering Wheel w/Audio and Bluetooth ● ● ● ● 倒车视频影像 Visual Imaging System ● ● ● ● 倒车雷达 Reverse Sensor ● ● ● ● 眼镜盒 glasses case - - - - 内后视镜 Interior rearview mirror - - - - 主副驾上储物盒 Upper storage box of driver and passenger ● ● ● ● 点烟器和烟灰缸 Cigarette lighter and ashtray ● ● ● ● 行车电脑显示屏 ECU Monitor ● ● ● ● 一键启动 One touch start ● ● ● ● 无匙进入 Keyless entry ● ● ● ● 座椅配置 Seat Equipment
座椅材质 Seat Material PU Leather PU Leather PU Leather PU Leather 主驾电动座椅 Main driving electric seat ― ― ― ― 驾驶座座椅调节 Driver's seat adjustment Manual 4-way adjustment Manual 4-way adjustment Manual 4-way adjustment Manual 4-way adjustment 副驾驶座座椅调节 Front passenger seat adjustment Manual 4-way adjustment Manual 4-way adjustment Manual 4-way adjustment Manual 4-way adjustment 多媒体配置 Multimedia Equipment
GPS导航系统 GPS System ● ● ● ● 中控台彩色大屏 Colourful Screen ● ● ● ● 蓝牙/车载电话 Bluetooth/Car telephone ● ● ● ● 外接音源接口 Sound Source Connector USB+AUX USB+AUX USB+AUX USB+AUX 扬声器数量 Speaker 4 2 4 2 灯光配置 Lighting Equipment
近光灯 Dipped Headlight Halogen Halogen Halogen Halogen 远光灯 Full Beam Headlight Halogen Halogen Halogen Halogen 前雾灯 Front Lamp ● ● ● ● 大灯高度可调 Electric Height-adjustable Headlamps ● ● ● ● 顶部照明 Top lighting ● ● ● ● 门灯 Door lamp ● ● ● ● 玻璃/后视镜 Window/Rear View Mirror
前/后电动车窗 Front/Rear Window Electric Electric Electric Electric 折叠后视镜 Folding Rearview ― ― ― ― 后视镜电动调节 Electrical Control Rear View Mirror ● ● ● ● 空调/冰箱 Air Condition
空调控制方式 Electric Control Air Conditioning electric electric electric electric
